Modern oscilloscopes must meet additional demands without neglecting the advantages of their predecessors. Oscilloscopes, which are user selectable between the analog and the digital mode, are undoubtedly the most versatile displaying instruments and meet this requirement. In spite of additional functions, such instruments must be user friendly and easy to operate.
The main demands for signal display and measurement are:
• bright and sharp trace
• time base, single event capturing, XY and component test mode
• signal amplifiers with high bandwidth and wide dynamic range
• distortion free probe tip to screen signal display
• high input sensitivity with minimum noise
• wide range of Y and X deflection coefficients
• stable triggering with multiple coupling modes
• delayed time base mode with second trigger system
• automatic signal related instrumentand cursor set up
•manual cursor supported measurement
• 8 kit low noise flash A/D converter for each channel
• 2048 byte displayable record length for each actual and reference signal
• high data acquisition and display rates
• refresh, envelope, average and roll mode
• pre and post trigger signal recording
• serial interface for PC supported documentation
• readout parameter display
• mu metal screened cRT display for highest resolution
• calibrator signals for low and high frequency probe adjustment
